Dual-zone climate chamber

A dual-zone climate chamber is available for carrying out experiments.

By means of a separating wall, the climate chamber is subdivided into two zones of equal size – the interior climate zone (representing the climate inside the building) and the exterior climate zone (representing the climate outside the building). Different air conditions (such as winter or summer) can be achieved in each zone. Both chambers can be accessed from the outside through two separate doors. The separating wall can be removed entirely and it is quite simple to incorporate components such as windows, façade elements, doors, etc. It is also possible to fit different air outlets and inlets, a perforated ceiling or a double floor.

The climate chamber possesses the following characteristics:

  • A dual-zone system with an interior and exterior zone
  • Volume of chamber: 64 m³
  • Interior zone: V = 32.1 m³, A = 9.7 m²
  • Exterior zone: V = 32.1 m³, A = 9.7 m²
  • External insulation: 160 mm of PU foam
  • Zone separation wall: 320 mm of PU foam

The incoming air to the interior and exterior zone is conditioned by two separate, full-service air conditioners providing all thermodynamic air treatment functions.

Interior zone
Climate chamber

Technical Center - Rednitzhembach

A research facility of the Institute for Energy and Building (ieg) of Nuremberg Institute of Technology.

Key features of the Technical Center:

  • R&D projects in cooperation with Nuremberg Institute of Technology
  • Students are involved in carrying out projects in the form of final theses
  • Access to various subject areas/expertise within the university
  • Services (including individual measurements, component testing, solving detailed problems)
  • Emulation test bench for technical building services components
  • Technikum Rednitzhembach
    Technikum Rednitzhembach
  • Technikum Rednitzhembach

Areas of activity:

Wastewater treatment:

  • Membrane technology, such as reverse osmosis systems
  • Physico-chemical treatment

Applied Chemistry:

  • Extraction processes
  • Material recovery

Energy process technology and process technology:

  • Combustion
  • Pyrolysis
  • Melting down
  • Energy recovery
  • Heat recycling
  • Thermal finishing of intermediates
  • Material recovery
  • Corrosion problems
  • Flue gas purification
  • Burner technology, burner utilization, and burner operation

Facility technology:

  • Expanding the range of R&D activities by constructing test benches
  • Researching and testing processes and systems for the integration of efficient, individual components (systems) into existing systems and buildings
  • Performance measurements on heat pumps or combined heat and power plants for component manufacturers
  • Experimental installations for Stirling machines with liquid piston compressors and biomass boilers with testing facilities for exhaust gas filters
  • Technikum Rednitzhembach
    Technikum Rednitzhembach
  • Technikum Rednitzhembach

Equipment installed

  • Wood pellet boiler (15-21 kW)
  • Wood chipping fired boiler/wood pellet boiler (28-35 kW)
  • Heat exchanger (air, 44 kW)
  • Cooling tower (250 kW)
  • Short rotary furnace/rotary furnace (500 kW)
  • Cyclonic combustion (melting) chamber (500 kW)
  • Oxygen/solid fuel burner
  • Pneumatic bulk material conveyor system (for the loading of reactors or burners)
  • Cantilever sifter (sifting area: 0.45 m²)
  • Hot gas particulate filter (3,300 m³/h, 450 °C) for the purification of flue gas
  • Activated carbon fixed-bed adsorber for the purification of flue gas
  • Induced draught fan (radial ventilator, 6,000 m³/h, 11,000 Pa)
  • Reverse osmosis system (wastewater treatment)
  • Cooling unit (100 kW)
  • Emulation and measurement test bench for the evaluation of the system dynamics of heat pumps, cooling units, combined heat and power plants and micro-CHP systems
